MJF6388G دیتاشیت

MJF6388G

مشخصات دیتاشیت

نام دیتاشیت MJF6388G
حجم فایل 105.918 کیلوبایت
نوع فایل pdf
تعداد صفحات 8

دانلود دیتاشیت MJF6388G

دانلود دیتاشیت

سایر مستندات

MJF6388, MJF6668 8 pages

مشخصات فنی

  • RoHS: true
  • Category: Triode/MOS Tube/Transistor/Darlington Transistors
  • Datasheet: onsemi MJF6388G
  • Transistor Type: NPN
  • Operating Temperature: -65°C~+150°C@(Tj)
  • Collector Current (Ic): 10A
  • Power Dissipation (Pd): 2W
  • Transition frequency (fT): -
  • DC current gain (hFE@Vce,Ic): 3000@4V,3A
  • Collector-emitter voltage (Vceo): 100V
  • Collector cut-off current (Icbo@Vcb): 10uA
  • Collector-emitter saturation voltage (VCE(sat)@Ic,Ib): 3V@10A,100mA
  • Package: TO-220F
  • Manufacturer: onsemi
  • Series: -
  • Packaging: Tube
  • Part Status: Obsolete
  • Current - Collector (Ic) (Max): 10A
  • Voltage - Collector Emitter Breakdown (Max): 100V
  • Vce Saturation (Max) @ Ib, Ic: 3V @ 100mA, 10A
  • Current - Collector Cutoff (Max): 10µA
  • DC Current Gain (hFE) (Min) @ Ic, Vce: 3000 @ 3A, 4V
  • Power - Max: 2W
  • Frequency - Transition: -
  • Mounting Type: Through Hole
  • Package / Case: TO-220-3 Full Pack
  • Supplier Device Package: TO-220FP
  • Base Part Number: MJF63
  • detail: Bipolar (BJT) Transistor NPN - Darlington 100V 10A 2W Through Hole TO-220FP
