دیتاشیت NTH027N65S3F-F155

NTH027N65S3F

مشخصات دیتاشیت

نام دیتاشیت NTH027N65S3F
حجم فایل 520.461 کیلوبایت
نوع فایل pdf
تعداد صفحات 10

دانلود دیتاشیت NTH027N65S3F

NTH027N65S3F Datasheet

مشخصات

  • Manufacturer: ON Semiconductor
  • Series: FRFET®, SuperFET® II
  • Packaging: Tube
  • Part Status: Active
  • FET Type: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss): 650V
  • Current - Continuous Drain (Id) @ 25°C: 75A (Tc)
  • Drive Voltage (Max Rds On, Min Rds On): 10V
  • Rds On (Max) @ Id, Vgs: 27.4mOhm @ 35A, 10V
  • Vgs(th) (Max) @ Id: 5V @ 7.5mA
  • Gate Charge (Qg) (Max) @ Vgs: 259nC @ 10V
  • Vgs (Max): ±30V
  • Input Capacitance (Ciss) (Max) @ Vds: 7690pF @ 400V
  • FET Feature: -
  • Power Dissipation (Max): 595W (Tc)
  • Operating Temperature: -55°C ~ 150°C (TJ)
  • Mounting Type: Through Hole
  • Supplier Device Package: TO-247-3
  • Package / Case: TO-247-3
  • Base Part Number: NTH027
  • detail: N-Channel 650V 75A (Tc) 595W (Tc) Through Hole TO-247-3
