NSD070ALT1G دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت NSD070ALT1G	دانلود دیتاشیت

RoHS: true
Category: Diodes/Switching Diode
Datasheet: onsemi NSD070ALT1G
Power Dissipation: 225mW
Diode Configuration: 1 Pair Common Anode
Reverse Voltage (Vr): 70V
Operating Temperature: -65°C~+150°C@(Tj)
Forward Voltage (Vf@If): 1.25V@150mA
Reverse Leakage Current: 5nA@70V
Reverse Recovery Time (trr): 3us
Average Rectified Current (Io): 200mA
Package: SOT-23(TO-236)
Manufacturer: onsemi
Series: Automotive, AEC-Q101
Packaging: Cut Tape (CT)
Part Status: Active
Diode Type: Standard
Voltage - DC Reverse (Vr) (Max): 70V
Current - Average Rectified (Io) (per Diode): 200mA
Voltage - Forward (Vf) (Max) @ If: 1.25V @ 150mA
Speed: Small Signal =< 200mA (Io), Any Speed
Current - Reverse Leakage @ Vr: 5nA @ 70V
Operating Temperature - Junction: -65°C ~ 150°C
Mounting Type: Surface Mount
Package / Case: TO-236-3, SC-59, SOT-23-3
Supplier Device Package: SOT-23-3 (TO-236)
Base Part Number: NSD070
detail: Diode Array 1 Pair Common Anode Standard 70V 200mA Surface Mount TO-236-3, SC-59, SOT-23-3
