دیتاشیت 2SD1802S-TL-E

2SB1202/2SD1802

مشخصات دیتاشیت

نام دیتاشیت 2SB1202/2SD1802
حجم فایل 277.814 کیلوبایت
نوع فایل pdf
تعداد صفحات 7

دانلود دیتاشیت 2SB1202/2SD1802

2SB1202/2SD1802 Datasheet

مشخصات

  • Manufacturer: ON Semiconductor
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Transistor Type: NPN
  • Current - Collector (Ic) (Max): 3A
  • Voltage - Collector Emitter Breakdown (Max): 50V
  • Vce Saturation (Max) @ Ib, Ic: 500mV @ 100mA, 2A
  • Current - Collector Cutoff (Max): 1µA (ICBO)
  • DC Current Gain (hFE) (Min) @ Ic, Vce: 140 @ 100mA, 2V
  • Power - Max: 1W
  • Frequency - Transition: 150MHz
  • Operating Temperature: 150°C (TJ)
  • Mounting Type: Surface Mount
  • Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
  • Supplier Device Package: 2-TP-FA
  • Base Part Number: 2SD1802
  • detail: Bipolar (BJT) Transistor NPN 50V 3A 150MHz 1W Surface Mount 2-TP-FA
