دیتاشیت NJVMJD44H11RLG-VF01

MJD44H11, MJD45H11

مشخصات دیتاشیت

نام دیتاشیت MJD44H11, MJD45H11
حجم فایل 93.654 کیلوبایت
نوع فایل pdf
تعداد صفحات 9

دانلود دیتاشیت MJD44H11, MJD45H11

MJD44H11, MJD45H11 Datasheet

مشخصات

  • Manufacturer: ON Semiconductor
  • Series: Automotive, AEC-Q101
  • Packaging: Tape & Reel (TR)
  • Part Status: Active
  • Transistor Type: NPN
  • Current - Collector (Ic) (Max): 8A
  • Voltage - Collector Emitter Breakdown (Max): 80V
  • Vce Saturation (Max) @ Ib, Ic: 1V @ 400mA, 8A
  • Current - Collector Cutoff (Max): 1µA
  • DC Current Gain (hFE) (Min) @ Ic, Vce: 60 @ 2A, 1V
  • Power - Max: 1.75W
  • Frequency - Transition: 85MHz
  • Operating Temperature: -55°C ~ 150°C (TJ)
  • Mounting Type: Surface Mount
  • Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
  • Supplier Device Package: DPAK
  • Base Part Number: NJVMJD44
  • detail: Bipolar (BJT) Transistor NPN 80V 8A 85MHz 1.75W Surface Mount DPAK
