NCP1589DMNTWG دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت NCP1589DMNTWG	دانلود دیتاشیت

RoHS: true
Category: Power Supply Chip/DC-DC Converters
Function: Step-down type
Topology: Step-down
Datasheet: onsemi NCP1589DMNTWG
Output Type: -
Number of Outputs: 1
Switching Frequency: -
Operating Temperature: 0°C~+95°C@(TA)
Synchronous Rectification: Yes
Package: DFN-10(3x3)
Manufacturer: onsemi
Series: -
Packaging: Cut Tape (CT)
Part Status: Active
Output Configuration: Positive
Output Phases: 1
Voltage - Supply (Vcc/Vdd): 4.5V ~ 13.2V
Frequency - Switching: -
Duty Cycle (Max): 83%
Synchronous Rectifier: Yes
Clock Sync: No
Serial Interfaces: -
Control Features: Enable, Power Good
Mounting Type: Surface Mount
Package / Case: 10-VFDFN Exposed Pad
Supplier Device Package: 10-DFN (3x3)
Base Part Number: NCP1589
detail: Buck Regulator Positive Output Step-Down DC-DC Controller IC 10-DFN (3x3)
