دیتاشیت BD434S

BD433-38

مشخصات دیتاشیت

نام دیتاشیت BD433-38
حجم فایل 50.695 کیلوبایت
نوع فایل pdf
تعداد صفحات 4

دانلود دیتاشیت BD433-38

BD433-38 Datasheet

مشخصات

  • RoHS: true
  • Category: Triode/MOS Tube/Transistor/Bipolar Transistors - BJT
  • Datasheet: onsemi BD434S
  • Transistor Type: PNP
  • Operating Temperature: +150°C@(Tj)
  • Collector Current (Ic): 4A
  • Power Dissipation (Pd): 36W
  • Transition Frequency (fT): 3MHz
  • DC Current Gain (hFE@Ic,Vce): 40@10mA,5V
  • Collector Cut-Off Current (Icbo): 100uA
  • Collector-Emitter Breakdown Voltage (Vceo): 22V
  • Collector-Emitter Saturation Voltage (VCE(sat)@Ic,Ib): 200mV@2A,200mA
  • Package: TO-126-3
  • Manufacturer: onsemi
  • Series: -
  • Packaging: Tube
  • Part Status: Obsolete
  • Current - Collector (Ic) (Max): 4A
  • Voltage - Collector Emitter Breakdown (Max): 22V
  • Vce Saturation (Max) @ Ib, Ic: 500mV @ 200mA, 2A
  • Current - Collector Cutoff (Max): 100µA
  • DC Current Gain (hFE) (Min) @ Ic, Vce: 40 @ 10mA, 5V
  • Power - Max: 36W
  • Frequency - Transition: 3MHz
  • Mounting Type: Through Hole
  • Package / Case: TO-225AA, TO-126-3
  • Supplier Device Package: SOT-32-3
  • Base Part Number: BD434
  • detail: Bipolar (BJT) Transistor PNP 22V 4A 3MHz 36W Through Hole SOT-32-3
