2SC6017-E دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
2SC6017-E
|
|
حجم فایل
|
62.258
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
10
|
مشخصات فنی
-
RoHS:
true
-
Category:
Triode/MOS Tube/Transistor/Bipolar Transistors - BJT
-
Datasheet:
onsemi 2SC6017-E
-
Transistor Type:
NPN
-
Operating Temperature:
+150°C@(Tj)
-
Collector Current (Ic):
10A
-
Power Dissipation (Pd):
950mW
-
Transition Frequency (fT):
200MHz
-
DC Current Gain (hFE@Ic,Vce):
200@1A,2V
-
Collector Cut-Off Current (Icbo):
10uA
-
Collector-Emitter Breakdown Voltage (Vceo):
50V
-
Collector-Emitter Saturation Voltage (VCE(sat)@Ic,Ib):
180mV@5A,250mA
-
Package:
TO-251-3
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Bulk
-
Part Status:
Not For New Designs
-
Current - Collector (Ic) (Max):
10A
-
Voltage - Collector Emitter Breakdown (Max):
50V
-
Vce Saturation (Max) @ Ib, Ic:
360mV @ 250mA, 5A
-
Current - Collector Cutoff (Max):
10µA (ICBO)
-
DC Current Gain (hFE) (Min) @ Ic, Vce:
200 @ 1A, 2V
-
Power - Max:
950mW
-
Frequency - Transition:
200MHz
-
Mounting Type:
Through Hole
-
Package / Case:
TO-251-3 Short Leads, IPak, TO-251AA
-
Supplier Device Package:
TP
-
Base Part Number:
2SC6017
-
detail:
Bipolar (BJT) Transistor NPN 50V 10A 200MHz 950mW Through Hole TP
