FCMT180N65S3 دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
FCMT180N65S3
|
|
حجم فایل
|
363.839
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
10
|
مشخصات فنی
-
Manufacturer:
ON Semiconductor
-
Series:
SuperFET® III
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
FET Type:
N-Channel
-
Technology:
MOSFET (Metal Oxide)
-
Drain to Source Voltage (Vdss):
650V
-
Current - Continuous Drain (Id) @ 25°C:
17A (Tc)
-
Drive Voltage (Max Rds On, Min Rds On):
10V
-
Rds On (Max) @ Id, Vgs:
180mOhm @ 8.5A, 10V
-
Vgs(th) (Max) @ Id:
4.5V @ 1.8mA
-
Gate Charge (Qg) (Max) @ Vgs:
33nC @ 10V
-
Vgs (Max):
±30V
-
Input Capacitance (Ciss) (Max) @ Vds:
1350pF @ 400V
-
FET Feature:
-
-
Power Dissipation (Max):
139W (Tc)
-
Operating Temperature:
-55°C ~ 150°C (TJ)
-
Mounting Type:
Surface Mount
-
Supplier Device Package:
Power88
-
Package / Case:
4-PowerTSFN
-
Base Part Number:
FCMT180
-
detail:
N-Channel 650V 17A (Tc) 139W (Tc) Surface Mount Power88
