FCU600N65S3R0 دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
FCU600N65S3R0
|
|
حجم فایل
|
295.579
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
10
|
مشخصات فنی
-
Manufacturer:
ON Semiconductor
-
Series:
SuperFET® III
-
Packaging:
Tube
-
Part Status:
Active
-
FET Type:
N-Channel
-
Technology:
MOSFET (Metal Oxide)
-
Drain to Source Voltage (Vdss):
650V
-
Current - Continuous Drain (Id) @ 25°C:
6A (Tc)
-
Drive Voltage (Max Rds On, Min Rds On):
10V
-
Rds On (Max) @ Id, Vgs:
600mOhm @ 3A, 10V
-
Vgs(th) (Max) @ Id:
4.5V @ 600µA
-
Gate Charge (Qg) (Max) @ Vgs:
11nC @ 10V
-
Vgs (Max):
±30V
-
Input Capacitance (Ciss) (Max) @ Vds:
465pF @ 400V
-
FET Feature:
-
-
Power Dissipation (Max):
54W (Tc)
-
Operating Temperature:
-55°C ~ 150°C (TJ)
-
Mounting Type:
Through Hole
-
Supplier Device Package:
I-PAK
-
Package / Case:
TO-251-3 Stub Leads, IPak
-
Base Part Number:
FCU600
-
detail:
N-Channel 650V 6A (Tc) 54W (Tc) Through Hole I-PAK
