دیتاشیت FDP038AN06A0

FDP038AN06A0, FDI038AN06A0

مشخصات دیتاشیت

نام دیتاشیت FDP038AN06A0, FDI038AN06A0
حجم فایل 554.036 کیلوبایت
نوع فایل pdf
تعداد صفحات 12

دانلود دیتاشیت FDP038AN06A0, FDI038AN06A0

FDP038AN06A0, FDI038AN06A0 Datasheet

مشخصات

  • Manufacturer: ON Semiconductor
  • Series: PowerTrench®
  • Packaging: Tube
  • Part Status: Active
  • FET Type: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss): 60V
  • Current - Continuous Drain (Id) @ 25°C: 17A (Ta), 80A (Tc)
  • Drive Voltage (Max Rds On, Min Rds On): 6V, 10V
  • Rds On (Max) @ Id, Vgs: 3.8mOhm @ 80A, 10V
  • Vgs(th) (Max) @ Id: 4V @ 250µA
  • Gate Charge (Qg) (Max) @ Vgs: 124nC @ 10V
  • Vgs (Max): ±20V
  • Input Capacitance (Ciss) (Max) @ Vds: 6400pF @ 25V
  • FET Feature: -
  • Power Dissipation (Max): 310W (Tc)
  • Operating Temperature: -55°C ~ 175°C (TJ)
  • Mounting Type: Through Hole
  • Supplier Device Package: TO-220-3
  • Package / Case: TO-220-3
  • Base Part Number: FDP038
  • detail: N-Channel 60V 17A (Ta), 80A (Tc) 310W (Tc) Through Hole TO-220-3
