FFSD2065B دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
FFSD2065B
|
|
حجم فایل
|
83.659
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
6
|
مشخصات فنی
-
RoHS:
true
-
Category:
Diodes/Schottky Barrier Diodes (SBD)
-
Datasheet:
onsemi FFSD2065B
-
Diode Configuration:
Single
-
Reverse Voltage (Vr):
650V
-
Forward Voltage (Vf@If):
1.38V@20A
-
Reverse Leakage Current (Ir):
0.5uA@650V
-
Average Rectified Current (Io):
23.4A
-
Package:
DPAK-3
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Diode Type:
Silicon Carbide Schottky
-
Voltage - DC Reverse (Vr) (Max):
650V
-
Current - Average Rectified (Io):
23.4A (DC)
-
Voltage - Forward (Vf) (Max) @ If:
1.7V @ 20A
-
Speed:
No Recovery Time > 500mA (Io)
-
Reverse Recovery Time (trr):
0ns
-
Current - Reverse Leakage @ Vr:
40µA @ 650V
-
Capacitance @ Vr, F:
866pF @ 1V, 100kHz
-
Mounting Type:
Surface Mount
-
Package / Case:
TO-252-3, DPak (2 Leads + Tab), SC-63
-
Supplier Device Package:
D-PAK (TO-252)
-
Operating Temperature - Junction:
-55°C ~ 175°C
-
detail:
Diode Silicon Carbide Schottky 650V 23.4A (DC) Surface Mount D-PAK (TO-252)
