NVMFD5C462NT1G دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت NVMFD5C462NT1G	دانلود دیتاشیت

RoHS: true
Type: 2 N-Channel
Category: Triode/MOS Tube/Transistor/MOSFETs
Datasheet: onsemi NVMFD5C462NT1G
Operating Temperature: -55°C~+175°C@(Tj)
Power Dissipation (Pd): 50W
Total Gate Charge (Qg@Vgs): 16nC@10V
Drain Source Voltage (Vdss): 40V
Input Capacitance (Ciss@Vds): 1.02nF@25V
Continuous Drain Current (Id): 70A
Gate Threshold Voltage (Vgs(th)@Id): 3.5V@250uA
Reverse Transfer Capacitance (Crss@Vds): 21pF@25V
Drain Source On Resistance (RDS(on)@Vgs,Id): 4.5mΩ@10V,25A
Package: DFN-8(5x6)
Manufacturer: onsemi
Series: -
Packaging: Cut Tape (CT)
Part Status: Active
FET Type: 2 N-Channel (Dual)
FET Feature: Standard
Drain to Source Voltage (Vdss): 40V
Current - Continuous Drain (Id) @ 25°C: 17.6A (Ta), 70A (Tc)
Rds On (Max) @ Id, Vgs: 5.4mOhm @ 25A, 10V
Vgs(th) (Max) @ Id: 3.5V @ 250µA
Gate Charge (Qg) (Max) @ Vgs: 16nC @ 10V
Input Capacitance (Ciss) (Max) @ Vds: 1020pF @ 25V
Power - Max: 3.2W (Ta), 50W (Tc)
Mounting Type: Surface Mount
Package / Case: 8-PowerTDFN
Supplier Device Package: 8-DFN (5x6) Dual Flag (SO8FL-Dual)
Base Part Number: NVMFD5
detail: Mosfet Array 2 N-Channel (Dual) 40V 17.6A (Ta), 70A (Tc) 3.2W (Ta), 50W (Tc) Surface Mount 8-DFN (5x6) Dual Flag (SO8FL-Dual)
