NC7WZ86L8X دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
NC7WZ86L8X
|
|
حجم فایل
|
69.681
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
9
|
مشخصات فنی
-
RoHS:
true
-
Series:
7WZ
-
Category:
Logic ICs/Gates
-
Datasheet:
onsemi NC7WZ86L8X
-
Sink Current:
32mA
-
Source Current:
32mA
-
Supply Voltage:
1.65V~5.5V
-
Logic Gate Type:
XORGate
-
Number of Channels:
2
-
Operating Temperature:
-40°C~+85°C
-
Propagation Delay Time:
4.2ns@5V,50pF
-
Quiescent Current (Max):
1uA
-
Package:
MicroPak-8
-
Manufacturer:
onsemi
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Logic Type:
XOR (Exclusive OR)
-
Number of Circuits:
2
-
Number of Inputs:
2
-
Features:
-
-
Voltage - Supply:
1.65V ~ 5.5V
-
Current - Quiescent (Max):
1µA
-
Current - Output High, Low:
32mA, 32mA
-
Logic Level - Low:
-
-
Logic Level - High:
-
-
Max Propagation Delay @ V, Max CL:
4.2ns @ 5V, 50pF
-
Mounting Type:
Surface Mount
-
Supplier Device Package:
8-MicroPak™
-
Package / Case:
8-UFQFN
-
Base Part Number:
NC7WZ8
-
detail:
XOR (Exclusive OR) IC 2 Channel 8-MicroPak™
