NCP171AMX280275TCG دیتاشیت

NCP171AMX280275TCG

مشخصات دیتاشیت

نام دیتاشیت NCP171AMX280275TCG
حجم فایل 78.931 کیلوبایت
نوع فایل pdf
تعداد صفحات 22

دانلود دیتاشیت NCP171AMX280275TCG

دانلود دیتاشیت

سایر مستندات

NCP171 21 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/Linear Voltage Regulators (LDO)
  • Datasheet: onsemi NCP171AMX280275TCG
  • Output Current: 80mA
  • Output Voltage: 2.8V
  • Dropout Voltage: 0.075V@(80mA)
  • Output Polarity: positive
  • Number of Outputs: 2
  • Maximum Input Voltage: 5.5V
  • Operating Temperature: -40°C~+85°C@(Tj)
  • Quiescent Current (Ground Current): 95uA
  • Power Supply Rejection Ratio (PSRR): 65dB@(1kHz)
  • Package: DFN-4(1.2x1.2)
  • Manufacturer: onsemi
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Output Configuration: Positive
  • Output Type: Fixed
  • Number of Regulators: 2
  • Voltage - Input (Max): 5.5V
  • Voltage - Output (Min/Fixed): 2.8V
  • Voltage - Output (Max): -
  • Voltage Dropout (Max): 0.075V @ 80mA
  • Current - Output: 80mA
  • Current - Quiescent (Iq): 95µA
  • PSRR: 65dB (1kHz)
  • Control Features: Enable
  • Protection Features: Over Current, Over Temperature
  • Mounting Type: Surface Mount
  • Package / Case: 4-XDFN Exposed Pad
  • Supplier Device Package: 4-XDFN (1.2x1.2)
  • Base Part Number: NCP171
  • detail: Linear Voltage Regulator IC 2 Output 80mA 4-XDFN (1.2x1.2)
