دیتاشیت FAN48610BUC50X
مشخصات دیتاشیت
| نام دیتاشیت |
FAN48610
|
| حجم فایل |
662.035
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
13
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/DC-DC Converters
-
Function:
boost converterType
-
Topology:
Boost
-
Datasheet:
onsemi FAN48610BUC50X
-
Output Type:
Fixed
-
Input Voltage:
2.5V~4.5V
-
Output Voltage:
5V
-
Number of Outputs:
1
-
Switching Frequency:
2.5MHz
-
Output Current (Max):
1A
-
Operating Temperature:
-40°C~+85°C@(TA)
-
Synchronous Rectification:
Yes
-
Package:
WLCSP-9
-
Manufacturer:
onsemi
-
Series:
TinyBoost®
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Output Configuration:
Positive
-
Voltage - Input (Min):
2.5V
-
Voltage - Input (Max):
4.5V
-
Voltage - Output (Min/Fixed):
5V
-
Voltage - Output (Max):
-
-
Current - Output:
1A (Switch)
-
Frequency - Switching:
2.5MHz
-
Synchronous Rectifier:
Yes
-
Mounting Type:
Surface Mount
-
Package / Case:
9-UFBGA, WLCSP
-
Supplier Device Package:
9-WLCSP (1.21x1.21)
-
Base Part Number:
FAN48610
-
detail:
Boost Switching Regulator IC Positive Fixed 5V 1 Output 1A (Switch) 9-UFBGA, WLCSP
