NCV4949APDR2G دیتاشیت

NCV4949APDR2G

مشخصات دیتاشیت

نام دیتاشیت NCV4949APDR2G
حجم فایل 79.975 کیلوبایت
نوع فایل pdf
تعداد صفحات 14

مشاهده دیتاشیت NCV4949APDR2G

دانلود دیتاشیت

سایر مستندات

NCV4949A 12 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/Linear Voltage Regulators (LDO)
  • Datasheet: onsemi NCV4949APDR2G
  • Package: SOP-8-EP
  • Manufacturer: onsemi
  • Series: Automotive, AEC-Q100
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Output Configuration: Positive
  • Output Type: Fixed
  • Number of Regulators: 1
  • Voltage - Input (Max): 28V
  • Voltage - Output (Min/Fixed): 5V
  • Voltage - Output (Max): -
  • Voltage Dropout (Max): 0.5V @ 100mA
  • Current - Output: 100mA
  • Current - Quiescent (Iq): 260µA
  • Current - Supply (Max): 5mA
  • PSRR: -
  • Control Features: Reset
  • Protection Features: Over Temperature, Short Circuit
  • Operating Temperature: -40°C ~ 125°C
  • Mounting Type: Surface Mount
  • Package / Case: 8-SOIC (0.154", 3.90mm Width) Exposed Pad
  • Supplier Device Package: 8-SOIC-EP
  • Base Part Number: NCV4949
  • detail: Linear Voltage Regulator IC 1 Output 100mA 8-SOIC-EP
