دیتاشیت ASMB-TTE0-0A3A2

مشخصات دیتاشیت

دانلود دیتاشیت ASMB-TTE0-0A3A2	ASMB-TTE0-0A3A2 Datasheet

Manufacturer: Broadcom Limited
Series: -
Part Status: Obsolete
Color: Red, Green, Blue (RGB)
Configuration: Independent
Lens Color: -
Lens Transparency: Diffused
Millicandela Rating: 880mcd Red, 2300mcd Green, 440mcd Blue
Lens Style: Square with Flat Top
Lens Size: -
Voltage - Forward (Vf) (Typ): 2.1V Red, 3V Green, 3V Blue
Current - Test: 20mA Red, 20mA Green, 20mA Blue
Viewing Angle: 110°
Mounting Type: Surface Mount
Wavelength - Dominant: 623nm Red, 525nm Green, 469nm Blue
Wavelength - Peak: 632nm Red, 518nm Green, 464nm Blue
Features: IPx6, IPx8
Package / Case: 6-SMD, J-Lead
Supplier Device Package: 6-PLCC
Size / Dimension: 3.20mm L x 3.20mm W
Height (Max): 2.90mm
detail: Red, Green, Blue (RGB) 623nm Red, 525nm Green, 469nm Blue LED Indication - Discrete 2.1V Red, 3V Green, 3V Blue 6-SMD, J-Lead
