ESD5481MUT5G دیتاشیت

ESD5481MUT5G

مشخصات دیتاشیت

نام دیتاشیت ESD5481MUT5G
حجم فایل 77.718 کیلوبایت
نوع فایل pdf
تعداد صفحات 6

دانلود دیتاشیت ESD5481MUT5G

دانلود دیتاشیت

سایر مستندات

ESD5481MUT5G 6 pages

مشخصات فنی

  • RoHS: true
  • Category: TVS/Fuse/Board Level Protection/ESD Protection Devices
  • Polarity: Bi-Directional
  • Datasheet: onsemi ESD5481MUT5G
  • Number of Lines: 1
  • Clamping Voltage@Ipp: 12.4V
  • Operating Temperature: -55°C~+150°C@(Tj)
  • Breakdown Voltage (VBR): 5.7V
  • Peak Pulse Power(Ppp)@8/20us: -
  • Junction Capacitance(Cj)@1MHz: 12pF@1MHz
  • Peak Pulse Current(Ipp)@8/20us: 2A
  • Reverse Stand-Off Voltage (Vrwm): 5V
  • Package: X3-DFN-2
  • Manufacturer: onsemi
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Type: Zener
  • Bidirectional Channels: 1
  • Voltage - Reverse Standoff (Typ): 5V (Max)
  • Voltage - Breakdown (Min): 5.7V
  • Voltage - Clamping (Max) @ Ipp: 12.4V
  • Current - Peak Pulse (10/1000µs): 2A (8/20µs)
  • Power - Peak Pulse: -
  • Power Line Protection: No
  • Applications: General Purpose
  • Capacitance @ Frequency: 12pF @ 1MHz
  • Mounting Type: Surface Mount
  • Package / Case: 0201 (0603 Metric)
  • Supplier Device Package: 2-X3DFN (0.62x0.32)
  • Base Part Number: ESD54
  • detail: 12.4V Clamp 2A (8/20µs) Ipp Tvs Diode Surface Mount 2-X3DFN (0.62x0.32)
