ESD7571N2T5G دیتاشیت

ESD7571N2T5G

مشخصات دیتاشیت

نام دیتاشیت ESD7571N2T5G
حجم فایل 101.163 کیلوبایت
نوع فایل pdf
تعداد صفحات 7

دانلود دیتاشیت ESD7571N2T5G

دانلود دیتاشیت

سایر مستندات

ESD7571, SZESD7571 7 pages

مشخصات فنی

  • RoHS: true
  • Category: TVS/Fuse/Board Level Protection/ESD Protection Devices
  • Datasheet: onsemi ESD7571N2T5G
  • Clamping Voltage@Ipp: 15V
  • Operating Temperature: -55°C~+150°C@(Tj)
  • Breakdown Voltage (VBR): 7V
  • Peak Pulse Power(Ppp)@8/20us: -
  • Junction Capacitance(Cj)@1MHz: 0.24pF@1MHz
  • Reverse Stand-Off Voltage (Vrwm): 5.3V
  • Package: DFN1006-2(SOD-882)
  • Manufacturer: onsemi
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Type: Zener
  • Bidirectional Channels: 1
  • Voltage - Reverse Standoff (Typ): 5.3V (Max)
  • Voltage - Breakdown (Min): 7V
  • Voltage - Clamping (Max) @ Ipp: 15V
  • Current - Peak Pulse (10/1000µs): -
  • Power - Peak Pulse: -
  • Power Line Protection: No
  • Applications: General Purpose
  • Capacitance @ Frequency: 0.24pF @ 1MHz
  • Mounting Type: Surface Mount
  • Package / Case: 2-XDFN
  • Supplier Device Package: 2-X2DFN (1x0.6)
  • Base Part Number: ESD75
  • detail: 15V Clamp Ipp Tvs Diode Surface Mount 2-X2DFN (1x0.6)
