M74VHC1GT14DFT1G دیتاشیت

M74VHC1GT14DFT1G

مشخصات دیتاشیت

نام دیتاشیت M74VHC1GT14DFT1G
حجم فایل 99.729 کیلوبایت
نوع فایل pdf
تعداد صفحات 6

دانلود دیتاشیت M74VHC1GT14DFT1G

دانلود دیتاشیت

سایر مستندات

MC74VHC1GT14 6 pages

مشخصات فنی

  • RoHS: true
  • Series: 74VHC
  • Category: Logic ICs/Inverters
  • Datasheet: onsemi M74VHC1GT14DFT1G
  • Input Type: Schmitt Trigger
  • Sink Current: 8mA
  • Source Current: 8mA
  • Number of Inputs: 1
  • Number of Circuits: 1
  • Supply Current (Max): 1uA
  • Low level range (VIL): 0.35V~0.6V
  • Max Propagation Delay: 10.6ns@5V,50pF
  • Operating Temperature: -55°C~+125°C
  • High level range (VIH): 1.6V~2.1V
  • Supply Voltage(Single): 2V~5.5V
  • Package: SC-70-5
  • Manufacturer: onsemi
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Logic Type: Inverter
  • Features: Schmitt Trigger
  • Voltage - Supply: 3V ~ 5.5V
  • Current - Quiescent (Max): 1µA
  • Current - Output High, Low: 8mA, 8mA
  • Logic Level - Low: 0.35V ~ 0.6V
  • Logic Level - High: 1.6V ~ 2.1V
  • Max Propagation Delay @ V, Max CL: 10.6ns @ 5V, 50pF
  • Mounting Type: Surface Mount
  • Supplier Device Package: SC-88A (SC-70-5/SOT-353)
  • Package / Case: 5-TSSOP, SC-70-5, SOT-353
  • Base Part Number: M74VHC1
  • detail: Inverter IC 1 Channel Schmitt Trigger SC-88A (SC-70-5/SOT-353)
