دیتاشیت FFSP4065BDN-F085
مشخصات دیتاشیت
| نام دیتاشیت | FFSP4065BDN-F085 |
|---|---|
| حجم فایل | 234.34 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 6 |
دانلود دیتاشیت FFSP4065BDN-F085 |
FFSP4065BDN-F085 Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Diodes/Schottky Barrier Diodes (SBD)
- Datasheet: onsemi FFSP4065BDN-F085
- Diode Configuration: Dual Common Cathode
- Reverse Voltage (Vr): 650V
- Forward Voltage (Vf@If): 1.38V@20A
- Reverse Leakage Current (Ir): 500nA@650V
- Average Rectified Current (Io): 20A
- Package: TO-220-3
- Manufacturer: onsemi
- Series: Automotive, AEC-Q101
- Part Status: Active
- Diode Type: Silicon Carbide Schottky
- Voltage - DC Reverse (Vr) (Max): 650V
- Current - Average Rectified (Io): 20A (DC)
- Voltage - Forward (Vf) (Max) @ If: 1.7V @ 20A
- Speed: No Recovery Time > 500mA (Io)
- Reverse Recovery Time (trr): 0ns
- Current - Reverse Leakage @ Vr: 40µA @ 650V
- Capacitance @ Vr, F: 866pF @ 1V, 100kHz
- Mounting Type: Through Hole
- Package / Case: TO-220-3
- Supplier Device Package: TO-220-3
- Operating Temperature - Junction: -55°C ~ 175°C
- Base Part Number: FFSP40
- detail: Diode Silicon Carbide Schottky 650V 20A (DC) Through Hole TO-220-3
