دیتاشیت FCH47N60F-F085

FCH47N60F_F085

مشخصات دیتاشیت

نام دیتاشیت FCH47N60F_F085
حجم فایل 558.498 کیلوبایت
نوع فایل pdf
تعداد صفحات 6

دانلود دیتاشیت FCH47N60F_F085

FCH47N60F_F085 Datasheet

مشخصات

  • Manufacturer: ON Semiconductor
  • Series: Automotive, AEC-Q101, SuperFET™
  • Packaging: Tube
  • Part Status: Not For New Designs
  • FET Type: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss): 600V
  • Current - Continuous Drain (Id) @ 25°C: 47A (Tc)
  • Drive Voltage (Max Rds On, Min Rds On): 10V
  • Rds On (Max) @ Id, Vgs: 75mOhm @ 47A, 10V
  • Vgs(th) (Max) @ Id: 5V @ 250µA
  • Gate Charge (Qg) (Max) @ Vgs: 250nC @ 10V
  • Vgs (Max): ±30V
  • Input Capacitance (Ciss) (Max) @ Vds: 8000pF @ 25V
  • FET Feature: -
  • Power Dissipation (Max): 417W (Tc)
  • Operating Temperature: -55°C ~ 150°C (TJ)
  • Mounting Type: Through Hole
  • Supplier Device Package: TO-247-3
  • Package / Case: TO-247-3
  • Base Part Number: FCH47
  • detail: N-Channel 600V 47A (Tc) 417W (Tc) Through Hole TO-247-3
