NSR05T40XV2T5G دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
NSR05T40XV2T5G
|
|
حجم فایل
|
71.397
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
5
|
مشخصات فنی
-
RoHS:
true
-
Category:
Diodes/Schottky Barrier Diodes (SBD)
-
Datasheet:
onsemi NSR05T40XV2T5G
-
Reverse Voltage (Vr):
40V
-
Forward Voltage (Vf@If):
640mV@500mA
-
Reverse Leakage Current (Ir):
55uA@40V
-
Average Rectified Current (Io):
500mA
-
Package:
SOD-523
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Diode Type:
Schottky
-
Voltage - DC Reverse (Vr) (Max):
40V
-
Current - Average Rectified (Io):
500mA
-
Voltage - Forward (Vf) (Max) @ If:
640mV @ 500mA
-
Speed:
Fast Recovery =< 500ns, > 200mA (Io)
-
Reverse Recovery Time (trr):
20ns
-
Current - Reverse Leakage @ Vr:
55µA @ 40V
-
Capacitance @ Vr, F:
70pF @ 1V, 1MHz
-
Mounting Type:
Surface Mount
-
Package / Case:
SC-79, SOD-523
-
Supplier Device Package:
SOD-523
-
Operating Temperature - Junction:
-55°C ~ 150°C
-
Base Part Number:
NSR05T
-
detail:
Diode Schottky 40V 500mA Surface Mount SOD-523
