NCP137 دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
NCP137
|
|
حجم فایل
|
129.253
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
8
|
مشخصات فنی
-
RoHS:
true
-
Category:
Power Supply Chip/Linear Voltage Regulators (LDO)
-
Datasheet:
onsemi NCP137AFCTADJT2G
-
Output Type:
Adjustable
-
Output Current:
700mA
-
Output Voltage:
0.5V~3V
-
Dropout Voltage:
1.5V@(700mA)
-
Output Polarity:
positive
-
Number of Outputs:
1
-
Maximum Input Voltage:
5.5V
-
Operating Temperature:
-40°C~+85°C@(Ta)
-
Package:
WLCSP-6
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Output Configuration:
Positive
-
Number of Regulators:
1
-
Voltage - Input (Max):
5.5V
-
Voltage - Output (Min/Fixed):
0.5V
-
Voltage - Output (Max):
3V
-
Voltage Dropout (Max):
1.5V @ 700mA
-
Current - Output:
700mA
-
PSRR:
85dB ~ 75dB (1kHz)
-
Control Features:
Enable
-
Protection Features:
Under Voltage Lockout (UVLO)
-
Mounting Type:
Surface Mount
-
Package / Case:
6-XFBGA, WLCSP
-
Supplier Device Package:
6-WLCSP (1.2x0.80)
-
Base Part Number:
NCP137
-
detail:
Linear Voltage Regulator IC 1 Output 700mA 6-WLCSP (1.2x0.80)
