NSM80101MT1G دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
NSM80101MT1G
|
|
حجم فایل
|
114.574
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
6
|
مشخصات فنی
-
Manufacturer:
ON Semiconductor
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Transistor Type:
NPN + Diode (Isolated)
-
Current - Collector (Ic) (Max):
500mA
-
Voltage - Collector Emitter Breakdown (Max):
80V
-
Vce Saturation (Max) @ Ib, Ic:
300mV @ 10mA, 100mA
-
Current - Collector Cutoff (Max):
100nA
-
DC Current Gain (hFE) (Min) @ Ic, Vce:
120 @ 10mA, 1V
-
Power - Max:
400mW
-
Frequency - Transition:
150MHz
-
Operating Temperature:
-55°C ~ 150°C (TJ)
-
Mounting Type:
Surface Mount
-
Package / Case:
SC-74, SOT-457
-
Supplier Device Package:
SC-74
-
Base Part Number:
NSM801
-
detail:
Bipolar (BJT) Transistor NPN + Diode (Isolated) 80V 500mA 150MHz 400mW Surface Mount SC-74
