50A02CH-TL-E دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | 50A02CH-TL-E |
|---|---|
| حجم فایل | 53.423 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 5 |
دانلود دیتاشیت 50A02CH-TL-E |
دانلود دیتاشیت |
|---|
سایر مستندات
50A02CH 5 pages
50A02CH-TL-E 7 pages
مشخصات فنی
- RoHS: true
- Category: Triode/MOS Tube/Transistor/Bipolar Transistors - BJT
- Datasheet: onsemi 50A02CH-TL-E
- Transistor Type: PNP
- Collector Current (Ic): 500mA
- Power Dissipation (Pd): 700mW
- Transition Frequency (fT): 690MHz
- DC Current Gain (hFE@Ic,Vce): 200@10mA,2V
- Collector Cut-Off Current (Icbo): 100nA
- Collector-Emitter Breakdown Voltage (Vceo): 50V
- Collector-Emitter Saturation Voltage (VCE(sat)@Ic,Ib): 120mV@10mA,100mA
- Package: SC-59-3
- Manufacturer: onsemi
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Current - Collector (Ic) (Max): 500mA
- Voltage - Collector Emitter Breakdown (Max): 50V
- Vce Saturation (Max) @ Ib, Ic: 120mV @ 10mA, 100mA
- Current - Collector Cutoff (Max): 100nA (ICBO)
- DC Current Gain (hFE) (Min) @ Ic, Vce: 200 @ 10mA, 2V
- Power - Max: 700mW
- Frequency - Transition: 690MHz
- Operating Temperature: 150°C (TJ)
- Mounting Type: Surface Mount
- Package / Case: TO-236-3, SC-59, SOT-23-3
- Supplier Device Package: 3-CPH
- Base Part Number: 50A02
- detail: Bipolar (BJT) Transistor PNP 50V 500mA 690MHz 700mW Surface Mount 3-CPH
