SPZT2907AT1G دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | SPZT2907AT1G |
|---|---|
| حجم فایل | 92.729 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 6 |
دانلود دیتاشیت SPZT2907AT1G |
دانلود دیتاشیت |
|---|
سایر مستندات
PZT2907A 4 pages
SPZT2907AT1G 4 pages
مشخصات فنی
- RoHS: true
- Category: Triode/MOS Tube/Transistor/Bipolar Transistors - BJT
- Datasheet: onsemi SPZT2907AT1G
- Transistor Type: PNP
- Collector Current (Ic): 600mA
- Power Dissipation (Pd): 1.5W
- Transition Frequency (fT): 200MHz
- DC Current Gain (hFE@Ic,Vce): 100@150mA,10V
- Collector Cut-Off Current (Icbo): 10nA
- Collector-Emitter Breakdown Voltage (Vceo): 60V
- Collector-Emitter Saturation Voltage (VCE(sat)@Ic,Ib): 1.6V@50mA,500mA
- Package: SOT-223-4
- Manufacturer: onsemi
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Current - Collector (Ic) (Max): 600mA
- Voltage - Collector Emitter Breakdown (Max): 60V
- Vce Saturation (Max) @ Ib, Ic: 1.6V @ 50mA, 500mA
- Current - Collector Cutoff (Max): 10nA (ICBO)
- DC Current Gain (hFE) (Min) @ Ic, Vce: 100 @ 150mA, 10V
- Power - Max: 1.5W
- Frequency - Transition: 200MHz
- Operating Temperature: -
- Mounting Type: Surface Mount
- Package / Case: TO-261-4, TO-261AA
- Supplier Device Package: SOT-223-3
- Base Part Number: SPZT29
- detail: Bipolar (BJT) Transistor PNP 60V 600mA 200MHz 1.5W Surface Mount SOT-223-3
