دیتاشیت ESDR0502NMUTAG

ESDR0502N

مشخصات دیتاشیت

نام دیتاشیت ESDR0502N
حجم فایل 155.725 کیلوبایت
نوع فایل pdf
تعداد صفحات 5

دانلود دیتاشیت ESDR0502N

ESDR0502N Datasheet

مشخصات

  • RoHS: true
  • Category: TVS/Fuse/Board Level Protection/ESD Protection Devices
  • Polarity: Unidirectional
  • Datasheet: onsemi ESDR0502NMUTAG
  • Number of Lines: 3
  • Clamping Voltage@Ipp: -
  • Operating Temperature: -40°C~+125°C@(Tj)
  • Breakdown Voltage (VBR): 6V
  • Peak Pulse Power(Ppp)@8/20us: 100W
  • Junction Capacitance(Cj)@1MHz: 0.3pF@1MHz
  • Reverse Stand-Off Voltage (Vrwm): 5.5V
  • Package: DFN-6(1x1.2)
  • Manufacturer: onsemi
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Type: Steering (Rail to Rail)
  • Unidirectional Channels: 3
  • Voltage - Reverse Standoff (Typ): 5.5V (Max)
  • Voltage - Breakdown (Min): 6V
  • Voltage - Clamping (Max) @ Ipp: -
  • Current - Peak Pulse (10/1000µs): -
  • Power - Peak Pulse: 100W
  • Power Line Protection: Yes
  • Applications: Ethernet
  • Capacitance @ Frequency: 0.3pF @ 1MHz
  • Mounting Type: Surface Mount
  • Package / Case: 6-UFDFN
  • Supplier Device Package: 6-UDFN (1.25x1)
  • Base Part Number: ESDR05
  • detail: Clamp Ipp Tvs Diode Surface Mount 6-UDFN (1.25x1)
