دیتاشیت FSV340FP

FSV340FP, FSV360FP

مشخصات دیتاشیت

نام دیتاشیت FSV340FP, FSV360FP
حجم فایل 146.088 کیلوبایت
نوع فایل pdf
تعداد صفحات 6

دانلود دیتاشیت FSV340FP, FSV360FP

FSV340FP, FSV360FP Datasheet

مشخصات

  • RoHS: true
  • Category: Diodes/Schottky Barrier Diodes (SBD)
  • Datasheet: onsemi FSV340FP
  • Diode Configuration: Single
  • Reverse Voltage (Vr): 40V
  • Forward Voltage (Vf@If): 520mV@3A
  • Reverse Leakage Current (Ir): 160uA@40V
  • Average Rectified Current (Io): 3A
  • Package: SOD-123EP
  • Manufacturer: onsemi
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Diode Type: Schottky
  • Voltage - DC Reverse (Vr) (Max): 40V
  • Current - Average Rectified (Io): 3A
  • Voltage - Forward (Vf) (Max) @ If: 520mV @ 3A
  • Speed: Fast Recovery =< 500ns, > 200mA (Io)
  • Reverse Recovery Time (trr): 12.37ns
  • Current - Reverse Leakage @ Vr: 160µA @ 40V
  • Capacitance @ Vr, F: -
  • Mounting Type: Surface Mount
  • Package / Case: SOD-123H
  • Supplier Device Package: SOD-123HE
  • Operating Temperature - Junction: -55°C ~ 150°C
  • Base Part Number: FSV340
  • detail: Diode Schottky 40V 3A Surface Mount SOD-123HE
