NC7S32L6X دیتاشیت

NC7S32L6X

مشخصات دیتاشیت

نام دیتاشیت NC7S32L6X
حجم فایل 66.269 کیلوبایت
نوع فایل pdf
تعداد صفحات 9

مشاهده دیتاشیت NC7S32L6X

دانلود دیتاشیت

سایر مستندات

NC7S32 9 pages

مشخصات فنی

  • RoHS: true
  • Series: 7S
  • Category: Logic ICs/Gates
  • Datasheet: onsemi NC7S32L6X
  • Sink Current: 2.6mA
  • Source Current: 2.6mA
  • Supply Voltage: 2V~6V
  • Logic Gate Type: ORGate
  • Number of Channels: 1
  • Low Level Range (VIL): 0.5V
  • Operating Temperature: -40°C~+85°C
  • High Level Range (VIH): 1.5V
  • Propagation Delay Time: 17ns@6V,50pF
  • Quiescent Current (Max): 1uA
  • Package: SIP-6
  • Manufacturer: onsemi
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Logic Type: OR Gate
  • Number of Circuits: 1
  • Number of Inputs: 2
  • Features: -
  • Voltage - Supply: 2V ~ 6V
  • Current - Quiescent (Max): 1µA
  • Current - Output High, Low: 2.6mA, 2.6mA
  • Logic Level - Low: 0.5V
  • Logic Level - High: 1.5V
  • Max Propagation Delay @ V, Max CL: 17ns @ 6V, 50pF
  • Mounting Type: Surface Mount
  • Supplier Device Package: 6-MicroPak
  • Package / Case: 6-UFDFN
  • Base Part Number: NC7S32
  • detail: OR Gate IC 1 Channel 6-MicroPak
