دیتاشیت MC74VHCT08ADR2G

MC74VHCT08A

مشخصات دیتاشیت

نام دیتاشیت MC74VHCT08A
حجم فایل 89.647 کیلوبایت
نوع فایل pdf
تعداد صفحات 6

دانلود دیتاشیت MC74VHCT08A

MC74VHCT08A Datasheet

مشخصات

  • Manufacturer: ON Semiconductor
  • Series: 74VHCT
  • Packaging: Tape & Reel (TR)
  • Part Status: Obsolete
  • Logic Type: AND Gate
  • Number of Circuits: 4
  • Number of Inputs: 2
  • Features: -
  • Voltage - Supply: 4.5V ~ 5.5V
  • Current - Quiescent (Max): 2µA
  • Current - Output High, Low: 8mA, 8mA
  • Logic Level - Low: 0.8V
  • Logic Level - High: 2V
  • Max Propagation Delay @ V, Max CL: 7.9ns @ 5V, 50pF
  • Operating Temperature: -40°C ~ 125°C
  • Mounting Type: Surface Mount
  • Supplier Device Package: 14-SOIC
  • Package / Case: 14-SOIC (0.154", 3.90mm Width)
  • Base Part Number: MC74VHCT08
  • detail: AND Gate IC 4 Channel 14-SOIC
