MCH3475-TL-E دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
MCH3475-TL-E
|
|
حجم فایل
|
59.841
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
5
|
مشخصات فنی
-
RoHS:
true
-
Type:
N Channel
-
Category:
Triode/MOS Tube/Transistor/MOSFETs
-
Datasheet:
onsemi MCH3475-TL-E
-
Operating Temperature:
+150°C@(Tj)
-
Power Dissipation (Pd):
800mW
-
Total Gate Charge (Qg@Vgs):
2nC@10V
-
Drain Source Voltage (Vdss):
30V
-
Input Capacitance (Ciss@Vds):
88pF@10V
-
Continuous Drain Current (Id):
1.8A
-
Gate Threshold Voltage (Vgs(th)@Id):
2.6V@1mA
-
Reverse Transfer Capacitance (Crss@Vds):
11pF@10V
-
Drain Source On Resistance (RDS(on)@Vgs,Id):
135mΩ@10V,0.9A
-
Package:
SOT-323(SC-70)
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Not For New Designs
-
FET Type:
N-Channel
-
Technology:
MOSFET (Metal Oxide)
-
Drain to Source Voltage (Vdss):
30V
-
Current - Continuous Drain (Id) @ 25°C:
1.8A (Ta)
-
Drive Voltage (Max Rds On, Min Rds On):
4V, 10V
-
Rds On (Max) @ Id, Vgs:
180mOhm @ 900mA, 10V
-
Vgs(th) (Max) @ Id:
-
-
Gate Charge (Qg) (Max) @ Vgs:
2nC @ 10V
-
Vgs (Max):
±20V
-
Input Capacitance (Ciss) (Max) @ Vds:
88pF @ 10V
-
FET Feature:
-
-
Power Dissipation (Max):
800mW (Ta)
-
Mounting Type:
Surface Mount
-
Supplier Device Package:
SC-70FL/MCPH3
-
Package / Case:
3-SMD, Flat Lead
-
Base Part Number:
MCH34
-
detail:
N-Channel 30V 1.8A (Ta) 800mW (Ta) Surface Mount SC-70FL/MCPH3
