دیتاشیت MC74VHC04DR2G
مشخصات دیتاشیت
| نام دیتاشیت |
MC74VHC04
|
| حجم فایل |
129.004
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
5
|
مشخصات
-
RoHS:
true
-
Series:
74VHC
-
Category:
Logic ICs/Inverters
-
Datasheet:
onsemi MC74VHC04DR2G
-
Input Type:
-
-
Sink Current:
8mA
-
Source Current:
8mA
-
Number of Inputs:
1
-
Number of Circuits:
6
-
Supply Current (Max):
2uA
-
Low level range (VIL):
0.5V
-
Max Propagation Delay:
7.5ns@5V,50pF
-
Operating Temperature:
-40°C~+85°C
-
High level range (VIH):
1.5V
-
Supply Voltage(Single):
2V~5.5V
-
Package:
SOP-14
-
Manufacturer:
onsemi
-
Packaging:
Tape & Reel (TR)
-
Part Status:
Obsolete
-
Logic Type:
Inverter
-
Features:
-
-
Voltage - Supply:
2V ~ 5.5V
-
Current - Quiescent (Max):
2µA
-
Current - Output High, Low:
8mA, 8mA
-
Logic Level - Low:
0.5V
-
Logic Level - High:
1.5V
-
Max Propagation Delay @ V, Max CL:
7.5ns @ 5V, 50pF
-
Mounting Type:
Surface Mount
-
Supplier Device Package:
14-SOIC
-
Package / Case:
14-SOIC (0.154", 3.90mm Width)
-
Base Part Number:
MC74VHC04
-
detail:
Inverter IC 6 Channel 14-SOIC
