NSD914F3T5G دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
NSD914F3T5G
|
|
حجم فایل
|
74.615
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
4
|
مشخصات فنی
-
RoHS:
true
-
Category:
Diodes/Switching Diode
-
Datasheet:
onsemi NSD914F3T5G
-
Power Dissipation:
360mW
-
Diode Configuration:
Single
-
Reverse Voltage (Vr):
100V
-
Operating Temperature:
-55°C~+150°C@(Tj)
-
Forward Voltage (Vf@If):
1V@10mA
-
Reverse Leakage Current:
5uA@75V
-
Reverse Recovery Time (trr):
4ns
-
Average Rectified Current (Io):
200mA
-
Package:
SOT-1123
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Diode Type:
Standard
-
Voltage - DC Reverse (Vr) (Max):
100V
-
Current - Average Rectified (Io):
200mA (DC)
-
Voltage - Forward (Vf) (Max) @ If:
1V @ 10mA
-
Speed:
Small Signal =< 200mA (Io), Any Speed
-
Current - Reverse Leakage @ Vr:
5µA @ 75V
-
Capacitance @ Vr, F:
4pF @ 0V, 1MHz
-
Mounting Type:
Surface Mount
-
Package / Case:
SOT-1123
-
Supplier Device Package:
SOT-1123
-
Operating Temperature - Junction:
-55°C ~ 150°C
-
Base Part Number:
NSD914
-
detail:
Diode Standard 100V 200mA (DC) Surface Mount SOT-1123
