NSR0320XV6T1G دیتاشیت

NSR0320XV6T1G

مشخصات دیتاشیت

نام دیتاشیت NSR0320XV6T1G
حجم فایل 82.473 کیلوبایت
نوع فایل pdf
تعداد صفحات 5

دانلود دیتاشیت NSR0320XV6T1G

دانلود دیتاشیت

سایر مستندات

NSR0320XV6T1 3 pages

مشخصات فنی

  • RoHS: true
  • Category: Diodes/Schottky Barrier Diodes (SBD)
  • Datasheet: onsemi NSR0320XV6T1G
  • Diode Configuration: Single
  • Reverse Voltage (Vr): 23V
  • Forward Voltage (Vf@If): 450mV@900mA
  • Reverse Leakage Current (Ir): 10uA@15V
  • Average Rectified Current (Io): 1A
  • Package: SOT-563
  • Manufacturer: onsemi
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Obsolete
  • Diode Type: Schottky
  • Voltage - DC Reverse (Vr) (Max): 23V
  • Current - Average Rectified (Io): 1A (DC)
  • Voltage - Forward (Vf) (Max) @ If: 500mV @ 900mA
  • Speed: Fast Recovery =< 500ns, > 200mA (Io)
  • Current - Reverse Leakage @ Vr: 50µA @ 15V
  • Capacitance @ Vr, F: 35pF @ 5V, 1MHz
  • Mounting Type: Surface Mount
  • Package / Case: SOT-563, SOT-666
  • Supplier Device Package: SOT-563
  • Operating Temperature - Junction: 125°C (Max)
  • Base Part Number: NSR032
  • detail: Diode Schottky 23V 1A (DC) Surface Mount SOT-563
