NCV8114ASN280T1G دیتاشیت

NCV8114ASN280T1G

مشخصات دیتاشیت

نام دیتاشیت NCV8114ASN280T1G
حجم فایل 73.396 کیلوبایت
نوع فایل pdf
تعداد صفحات 13

دانلود دیتاشیت NCV8114ASN280T1G

دانلود دیتاشیت

سایر مستندات

NCV8114 12 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/Linear Voltage Regulators (LDO)
  • Datasheet: onsemi NCV8114ASN280T1G
  • Output Current: 300mA
  • Output Voltage: 2.8V
  • Dropout Voltage: 0.27V@(300mA)
  • Output Polarity: positive
  • Number of Outputs: 1
  • Maximum Input Voltage: 5.5V
  • Operating Temperature: -40°C~+125°C@(Ta)
  • Quiescent Current (Ground Current): 95uA
  • Power Supply Rejection Ratio (PSRR): 75dB@(1kHz)
  • Package: SOT-23-5
  • Manufacturer: onsemi
  • Series: Automotive, AEC-Q100
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Output Configuration: Positive
  • Output Type: Fixed
  • Number of Regulators: 1
  • Voltage - Input (Max): 5.5V
  • Voltage - Output (Min/Fixed): 2.8V
  • Voltage - Output (Max): -
  • Voltage Dropout (Max): 0.27V @ 300mA
  • Current - Output: 300mA
  • Current - Quiescent (Iq): 95µA
  • PSRR: 75dB (1kHz)
  • Control Features: Enable
  • Protection Features: Over Current, Over Temperature
  • Mounting Type: Surface Mount
  • Package / Case: SOT-23-5 Thin, TSOT-23-5
  • Supplier Device Package: 5-TSOP
  • Base Part Number: NCV8114
  • detail: Linear Voltage Regulator IC 1 Output 300mA 5-TSOP
