- دیتاشیت SZESD7241N2T5G
SZESD7241N2T5G دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | SZESD7241N2T5G |
|---|---|
| حجم فایل | 92.574 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 8 |
دانلود دیتاشیت SZESD7241N2T5G |
دانلود دیتاشیت |
|---|
سایر مستندات
ESD7241, SZESD7241 7 pages
مشخصات فنی
- RoHS: true
- Category: TVS/Fuse/Board Level Protection/ESD Protection Devices
- Datasheet: onsemi SZESD7241N2T5G
- Number of Lines: 1
- Clamping Voltage@Ipp: 48V
- Operating Temperature: -55°C~+150°C@(Tj)
- Breakdown Voltage (VBR): 24.3V
- Peak Pulse Power(Ppp)@8/20us: -
- Junction Capacitance(Cj)@1MHz: 1pF@1MHz
- Reverse Stand-Off Voltage (Vrwm): 24V
- Package: X2-DFN-2
- Manufacturer: onsemi
- Series: Automotive, AEC-Q101
- Packaging: Cut Tape (CT)
- Part Status: Active
- Type: Zener
- Bidirectional Channels: 1
- Voltage - Reverse Standoff (Typ): 24V (Max)
- Voltage - Breakdown (Min): 24.3V
- Voltage - Clamping (Max) @ Ipp: 48V (Typ)
- Current - Peak Pulse (10/1000µs): -
- Power - Peak Pulse: -
- Power Line Protection: No
- Applications: Automotive, RF Antenna
- Capacitance @ Frequency: 1pF @ 1MHz (Max)
- Mounting Type: Surface Mount
- Package / Case: 0402 (1006 Metric)
- Supplier Device Package: 2-X2DFN (1x0.6)
- Base Part Number: SZESD7
- detail: 48V (Typ) Clamp Ipp Tvs Diode Surface Mount 2-X2DFN (1x0.6)
