NC7SZ00L6X دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | NC7SZ00L6X |
|---|---|
| حجم فایل | 74.58 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 12 |
دانلود دیتاشیت NC7SZ00L6X |
دانلود دیتاشیت |
|---|
سایر مستندات
NC7SZ00 11 pages
NC7SZ00L6X 11 pages
مشخصات فنی
- RoHS: true
- Series: 7SZ
- Category: Logic ICs/Gates
- Datasheet: onsemi NC7SZ00L6X
- Sink Current: 32mA
- Source Current: 32mA
- Supply Voltage: 1.65V~5.5V
- Logic Gate Type: NAND Gates
- Number of Channels: 1
- Operating Temperature: -40°C~+85°C
- Propagation Delay Time: 4.3ns@5V,50pF
- Quiescent Current (Max): 2uA
- Package: MicroPak-6
- Manufacturer: onsemi
- Packaging: Cut Tape (CT)
- Part Status: Active
- Logic Type: NAND Gate
- Number of Circuits: 1
- Number of Inputs: 2
- Features: -
- Voltage - Supply: 1.65V ~ 5.5V
- Current - Quiescent (Max): 2µA
- Current - Output High, Low: 32mA, 32mA
- Logic Level - Low: -
- Logic Level - High: -
- Max Propagation Delay @ V, Max CL: 4.3ns @ 5V, 50pF
- Mounting Type: Surface Mount
- Supplier Device Package: 6-MicroPak
- Package / Case: 6-UFDFN
- Base Part Number: NC7SZ0
- detail: NAND Gate IC 1 Channel 6-MicroPak
