NLAST4599DTT1G دیتاشیت

مشخصات دیتاشیت

دانلود دیتاشیت NLAST4599DTT1G	دانلود دیتاشیت

RoHS: true
Category: Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
Datasheet: onsemi NLAST4599DTT1G
Switch Circuit: -
Package: SOT-23-6
Manufacturer: onsemi
Series: -
Packaging: Cut Tape (CT)
Part Status: Active
Multiplexer/Demultiplexer Circuit: 2:1
Number of Circuits: 1
On-State Resistance (Max): 25Ohm
Channel-to-Channel Matching (ΔRon): 2Ohm
Voltage - Supply, Single (V+): 2V ~ 5.5V
Voltage - Supply, Dual (V±): -
Switch Time (Ton, Toff) (Max): 14ns, 8ns
-3db Bandwidth: 200MHz
Charge Injection: 3pC
Channel Capacitance (CS(off), CD(off)): 10pF, 10pF
Current - Leakage (IS(off)) (Max): 1nA
Crosstalk: -
Operating Temperature: -55°C ~ 125°C (TA)
Mounting Type: Surface Mount
Package / Case: SOT-23-6 Thin, TSOT-23-6
Supplier Device Package: 6-TSOP
Base Part Number: NLAST45
detail: 1 Circuit IC Switch 2:1 25Ohm 6-TSOP
