دیتاشیت MCH6353-TL-W

MCH6353

مشخصات دیتاشیت

نام دیتاشیت MCH6353
حجم فایل 376.96 کیلوبایت
نوع فایل pdf
تعداد صفحات 6

دانلود دیتاشیت MCH6353

MCH6353 Datasheet

مشخصات

  • Manufacturer: ON Semiconductor
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • FET Type: P-Channel
  • Technology: MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss): 12V
  • Current - Continuous Drain (Id) @ 25°C: 6A (Ta)
  • Drive Voltage (Max Rds On, Min Rds On): 1.5V, 4.5V
  • Rds On (Max) @ Id, Vgs: 35mOhm @ 3A, 4.5V
  • Vgs(th) (Max) @ Id: -
  • Gate Charge (Qg) (Max) @ Vgs: 12nC @ 4.5V
  • Vgs (Max): ±10V
  • Input Capacitance (Ciss) (Max) @ Vds: 1250pF @ 6V
  • FET Feature: -
  • Power Dissipation (Max): 1.4W (Ta)
  • Operating Temperature: 150°C (TJ)
  • Mounting Type: Surface Mount
  • Supplier Device Package: 6-MCPH
  • Package / Case: 6-SMD, Flat Leads
  • Base Part Number: MCH63
  • detail: P-Channel 12V 6A (Ta) 1.4W (Ta) Surface Mount 6-MCPH
