دیتاشیت NRVHP120SFT3G

NHP120SF, NRVHP120SF

مشخصات دیتاشیت

نام دیتاشیت NHP120SF, NRVHP120SF
حجم فایل 116.884 کیلوبایت
نوع فایل pdf
تعداد صفحات 5

دانلود دیتاشیت NHP120SF, NRVHP120SF

NHP120SF, NRVHP120SF Datasheet

مشخصات

  • RoHS: true
  • Category: Diodes/Diodes - Fast Recovery Rectifiers
  • Reverse Voltage (Vr): 200V
  • Operating Temperature: -65°C~+175°C
  • Forward Voltage (Vf@If): 1V@1A
  • Reverse Leakage Current: 500nA@200V
  • Reverse Recovery Time (trr): 25ns
  • Package: SOD-123
  • Manufacturer: onsemi
  • Series: Automotive, AEC-Q101
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Diode Type: Standard
  • Voltage - DC Reverse (Vr) (Max): 200V
  • Current - Average Rectified (Io): 1A
  • Voltage - Forward (Vf) (Max) @ If: 1V @ 1A
  • Speed: Fast Recovery =< 500ns, > 200mA (Io)
  • Current - Reverse Leakage @ Vr: 500nA @ 200V
  • Capacitance @ Vr, F: -
  • Mounting Type: Surface Mount
  • Package / Case: SOD-123F
  • Supplier Device Package: SOD-123FL
  • Operating Temperature - Junction: -65°C ~ 175°C
  • Base Part Number: NRVHP12
  • detail: Diode Standard 200V 1A Surface Mount SOD-123FL
