EMI7112FCTAG دیتاشیت

EMI7112FCTAG

مشخصات دیتاشیت

نام دیتاشیت EMI7112FCTAG
حجم فایل 76.019 کیلوبایت
نوع فایل pdf
تعداد صفحات 6

مشاهده دیتاشیت EMI7112FCTAG

دانلود دیتاشیت

سایر مستندات

EMI7112 6 pages

مشخصات فنی

  • RoHS: true
  • Category: Bead/Filter/EMI Optimization/EMI Filters (LC, RC Networks)
  • Datasheet: onsemi EMI7112FCTAG
  • Capacitance: 250pF
  • Filter Order: 3
  • ESD Protection: Yes
  • Attenuation Value: 40dB@700MHz
  • Number of Channels: 2
  • OperatingTemperature: -40°C~+125°C
  • Frequency - Cutoff or Center: 20MHz
  • Package: WLCSP-5
  • Manufacturer: onsemi
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Type: Low Pass
  • Technology: LC (Pi)
  • Center / Cutoff Frequency: 20MHz (Cutoff)
  • Resistance - Channel (Ohms): 0.35
  • Current: 350mA
  • Values: C = 250pF (Total)
  • Operating Temperature: -40°C ~ 125°C
  • Applications: Data Lines for Mobile Devices
  • Voltage - Rated: -
  • Mounting Type: Surface Mount
  • Package / Case: 5-UFBGA, WLCSP
  • Size / Dimension: 0.050" L x 0.035" W (1.26mm x 0.89mm)
  • Height: 0.025" (0.64mm)
  • Base Part Number: EMI7112
  • detail: LC (Pi) EMI Filter 3rd Order Low Pass 2 Channel C = 250pF (Total) 350mA 5-UFBGA, WLCSP
