دیتاشیت SURA8260T3G
مشخصات دیتاشیت
| نام دیتاشیت | MURA260T3G, SURA8260T3G |
|---|---|
| حجم فایل | 54.389 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 5 |
دانلود دیتاشیت MURA260T3G, SURA8260T3G |
MURA260T3G, SURA8260T3G Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Diodes/Diodes - Fast Recovery Rectifiers
- Datasheet: onsemi SURA8260T3G
- Diode Configuration: -
- Reverse Voltage (Vr): 600V
- Operating Temperature: -65°C~+175°C@(Tj)
- Forward Voltage (Vf@If): 1.45V@2A
- Reverse Leakage Current: 5uA@600V
- Reverse Recovery Time (trr): 75ns
- Average Rectified Current (Io): 2A
- Package: SMA
- Manufacturer: onsemi
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Diode Type: Standard
- Voltage - DC Reverse (Vr) (Max): 600V
- Current - Average Rectified (Io): 2A
- Voltage - Forward (Vf) (Max) @ If: 1.45V @ 2A
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Current - Reverse Leakage @ Vr: 5µA @ 600V
- Capacitance @ Vr, F: -
- Mounting Type: Surface Mount
- Package / Case: DO-214AC, SMA
- Supplier Device Package: SMA
- Operating Temperature - Junction: -65°C ~ 175°C
- Base Part Number: SURA82
- detail: Diode Standard 600V 2A Surface Mount SMA
