BAS20HT1(G) دیتاشیت

BAS20HT1(G)

مشخصات دیتاشیت

نام دیتاشیت BAS20HT1(G)
حجم فایل 52.608 کیلوبایت
نوع فایل pdf
تعداد صفحات 3

مشاهده دیتاشیت BAS20HT1(G)

دانلود دیتاشیت

سایر مستندات

BAS20HT1G 3 pages

مشخصات فنی

  • RoHS: true
  • Category: Diodes/Switching Diode
  • Datasheet: onsemi SBAS20HT1G
  • Power Dissipation: 200mW
  • Diode Configuration: Single
  • Reverse Voltage (Vr): 200V
  • Operating Temperature: -55°C~+150°C@(Tj)
  • Forward Voltage (Vf@If): 1.25V@150mA
  • Reverse Leakage Current: 1uA@100V
  • Reverse Recovery Time (trr): 50ns
  • Average Rectified Current (Io): 200mA
  • Package: SOD-323
  • Manufacturer: onsemi
  • Series: -
  • Packaging: Tape & Reel (TR)
  • Part Status: Obsolete
  • Diode Type: Standard
  • Voltage - DC Reverse (Vr) (Max): 200V
  • Current - Average Rectified (Io): 200mA (DC)
  • Voltage - Forward (Vf) (Max) @ If: 1.25V @ 200mA
  • Speed: Small Signal =< 200mA (Io), Any Speed
  • Current - Reverse Leakage @ Vr: 1µA @ 200V
  • Capacitance @ Vr, F: 5pF @ 0V, 1MHz
  • Mounting Type: Surface Mount
  • Package / Case: SC-76, SOD-323
  • Supplier Device Package: SOD-323
  • Operating Temperature - Junction: -55°C ~ 150°C
  • Base Part Number: BAS20
  • detail: Diode Standard 200V 200mA (DC) Surface Mount SOD-323
