دیتاشیت MCH3481-TL-W

MCH3481

مشخصات دیتاشیت

نام دیتاشیت MCH3481
حجم فایل 666.615 کیلوبایت
نوع فایل pdf
تعداد صفحات 5

دانلود دیتاشیت MCH3481

MCH3481 Datasheet

مشخصات

  • Manufacturer: ON Semiconductor
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • FET Type: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss): 20V
  • Current - Continuous Drain (Id) @ 25°C: 2A (Ta)
  • Drive Voltage (Max Rds On, Min Rds On): 1.2V, 4.5V
  • Rds On (Max) @ Id, Vgs: 104mOhm @ 1A, 4.5V
  • Vgs(th) (Max) @ Id: 900mV @ 1mA
  • Gate Charge (Qg) (Max) @ Vgs: 2.9nC @ 4.5V
  • Vgs (Max): ±9V
  • Input Capacitance (Ciss) (Max) @ Vds: 175pF @ 10V
  • FET Feature: -
  • Power Dissipation (Max): 800mW (Ta)
  • Operating Temperature: 150°C (TJ)
  • Mounting Type: Surface Mount
  • Supplier Device Package: SC-70FL/MCPH3
  • Package / Case: 3-SMD, Flat Lead
  • Base Part Number: MCH34
  • detail: N-Channel 20V 2A (Ta) 800mW (Ta) Surface Mount SC-70FL/MCPH3
