دیتاشیت NUF4401MNT1G
مشخصات دیتاشیت
| نام دیتاشیت |
NUF4401MN
|
| حجم فایل |
130.454
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
6
|
مشخصات
-
RoHS:
true
-
Category:
Bead/Filter/EMI Optimization/EMI Filters (LC, RC Networks)
-
Datasheet:
onsemi NUF4401MNT1G
-
Capacitance:
15pF
-
Filter Order:
2
-
ESD Protection:
Yes
-
Attenuation Value:
35dB@900MHz~2.4GHz
-
Number of Channels:
4
-
OperatingTemperature:
-40°C~+85°C
-
Frequency - Cutoff or Center:
125MHz
-
Package:
DFN-8(2x2)
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Type:
Low Pass
-
Technology:
RC (Pi)
-
Center / Cutoff Frequency:
125MHz (Cutoff)
-
Resistance - Channel (Ohms):
200
-
Values:
R = 200Ohms, C = 15pF
-
Operating Temperature:
-40°C ~ 85°C
-
Applications:
Data Lines for Mobile Devices
-
Voltage - Rated:
-
-
Mounting Type:
Surface Mount
-
Package / Case:
8-VFDFN Exposed Pad
-
Size / Dimension:
0.079" L x 0.079" W (2.00mm x 2.00mm)
-
Height:
0.039" (1.00mm)
-
Base Part Number:
NUF4401
-
detail:
RC (Pi) EMI Filter 2nd Order Low Pass 4 Channel R = 200Ohms, C = 15pF 8-VFDFN Exposed Pad
