دیتاشیت NLAS5223MNR2G
مشخصات دیتاشیت
| نام دیتاشیت |
NLAS5223(L)
|
| حجم فایل |
105.174
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
10
|
مشخصات
-
RoHS:
true
-
Category:
Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
-
Datasheet:
onsemi NLAS5223MNR2G
-
Package:
WQFN-10(1.4x1.8)
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Switch Circuit:
SPDT
-
Multiplexer/Demultiplexer Circuit:
2:1
-
Number of Circuits:
2
-
On-State Resistance (Max):
300mOhm
-
Channel-to-Channel Matching (ΔRon):
50mOhm (Max)
-
Voltage - Supply, Single (V+):
1.65V ~ 3.6V
-
Voltage - Supply, Dual (V±):
-
-
Switch Time (Ton, Toff) (Max):
50ns, 30ns
-
-3db Bandwidth:
17MHz
-
Charge Injection:
38pC
-
Channel Capacitance (CS(off), CD(off)):
75pF
-
Current - Leakage (IS(off)) (Max):
500nA
-
Crosstalk:
-70dB @ 100kHz
-
Operating Temperature:
-40°C ~ 85°C (TA)
-
Mounting Type:
Surface Mount
-
Package / Case:
10-WFQFN
-
Supplier Device Package:
10-WQFN (1.4x1.8)
-
Base Part Number:
NLAS5
-
detail:
2 Circuit IC Switch 2:1 300mOhm 10-WQFN (1.4x1.8)
