دیتاشیت MCH3484-TL-W
مشخصات دیتاشیت
| نام دیتاشیت |
MCH3484
|
| حجم فایل |
310.045
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
5
|
مشخصات
-
RoHS:
true
-
Type:
N Channel
-
Category:
Triode/MOS Tube/Transistor/MOSFETs
-
Power Dissipation (Pd):
1W
-
Drain Source Voltage (Vdss):
20V
-
Continuous Drain Current (Id):
4.5A
-
Gate Threshold Voltage (Vgs(th)@Id):
800mV@1mA
-
Drain Source On Resistance (RDS(on)@Vgs,Id):
40mΩ@2.5V,2A
-
Package:
SC-70FL(MCPH-3)
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
FET Type:
N-Channel
-
Technology:
MOSFET (Metal Oxide)
-
Drain to Source Voltage (Vdss):
20V
-
Current - Continuous Drain (Id) @ 25°C:
4.5A (Ta)
-
Drive Voltage (Max Rds On, Min Rds On):
0.9V, 2.5V
-
Rds On (Max) @ Id, Vgs:
40mOhm @ 2A, 2.5V
-
Vgs(th) (Max) @ Id:
800mV @ 1mA
-
Gate Charge (Qg) (Max) @ Vgs:
11nC @ 2.5V
-
Vgs (Max):
±5V
-
Input Capacitance (Ciss) (Max) @ Vds:
630pF @ 10V
-
FET Feature:
-
-
Power Dissipation (Max):
1W (Ta)
-
Operating Temperature:
-55°C ~ 150°C (TJ)
-
Mounting Type:
Surface Mount
-
Supplier Device Package:
SC-70FL/MCPH3
-
Package / Case:
3-SMD, Flat Lead
-
Base Part Number:
MCH34
-
detail:
N-Channel 20V 4.5A (Ta) 1W (Ta) Surface Mount SC-70FL/MCPH3
