دیتاشیت CM1457-04CP
مشخصات دیتاشیت
| نام دیتاشیت |
CM1457
|
| حجم فایل |
190.662
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
7
|
مشخصات
-
RoHS:
true
-
Category:
Bead/Filter/EMI Optimization/EMI Filters (LC, RC Networks)
-
Datasheet:
onsemi CM1457-04CP
-
Capacitance:
12.5pF
-
Filter Order:
5
-
ESD Protection:
Yes
-
Attenuation Value:
35dB@800MHz~2.7GHz
-
Number of Channels:
4
-
OperatingTemperature:
-40°C~+85°C
-
Frequency - Cutoff or Center:
300MHz
-
Package:
CSP-10
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Type:
Low Pass
-
Technology:
LC (Pi)
-
Center / Cutoff Frequency:
300MHz (Cutoff)
-
Resistance - Channel (Ohms):
45
-
Current:
15mA
-
Values:
L = 70nH (Total), C = 12.5pF (Total)
-
Operating Temperature:
-40°C ~ 85°C
-
Applications:
Data Lines for Mobile Devices
-
Voltage - Rated:
-
-
Mounting Type:
Surface Mount
-
Package / Case:
10-WFBGA, WLCSP
-
Size / Dimension:
0.066" L x 0.041" W (1.67mm x 1.05mm)
-
Height:
0.027" (0.69mm)
-
Base Part Number:
CM1457
-
detail:
LC (Pi) EMI Filter 5th Order Low Pass 4 Channel L = 70nH (Total), C = 12.5pF (Total) 15mA 10-WFBGA, WLCSP
